Chapter 16: Using Blending Modes with Layers

A blending mode compares the content of two layers and enacts changes based on the content of both. You can choose from 14 different blending modes using the pop-up menu at the top of the Layers controls.  Understanding blending modes requires a bit of science.  To start let’s establish three key terms.

  • Base color. The original color in the image
  • Blend color. The color being applied by the top layer or Adjustment layer.
  • Result color. The color resulting from the blend

To adjust a layer’s Blending Mode is easy.

  1. Open a photo within Luminar.
  2. In the Layers controls click the + button and choose the Add New Image Layer option.
  3. For the top layer, click the Blend pop-up menu in the Layers control area.
  4. Choose from one of the 14 available blending modes.

Normal

The default mode performs no additional change to how layer contents interact.

Chapter 16: Using Blending Modes with Layers

Darken

Pixels lighter than blend are replaced; darker ones are not.

Chapter 16: Using Blending Modes with Layers(2)

Multiply

Is similar to drawing strokes on the image with markers. The colors of the top layer or blended with the image.

Chapter 16: Using Blending Modes with Layers(3)

Color Burn

Evaluates each channel; darkens base by increasing contrast.

Chapter 16: Using Blending Modes with Layers(4)

Lighten

Evaluates each channel; it then uses base or blend color (whichever is lighter).

Chapter 16: Using Blending Modes with Layers(5)

Screen

Uses a lighter color. It is useful for “knocking” black out of a layer.Overlay

Overlays existing pixels while preserving highlights and shadows of base.

Chapter 16: Using Blending Modes with Layers(6)

Overlay

Overlays existing pixels while preserving highlights and shadows of base.

Chapter 16: Using Blending Modes with Layers(7)

Soft Light

The effect is similar to shining a diffused spotlight on the image.

Chapter 16: Using Blending Modes with Layers(8)

Hard Light

Effect is similar to shining a harsh spotlight on the image.

Chapter 16: Using Blending Modes with Layers(9)

Difference

Evaluates each channel and subtracts or inverts depending on brightness.

Chapter 16: Using Blending Modes with Layers(10)

Subtract

Looks at the color in each channel and subtracts the blend from the base.

Chapter 16: Using Blending Modes with Layers(11)

Hue

Uses luminance and saturation of the base and the hue of the blend.

Chapter 16: Using Blending Modes with Layers(12)

Color

Preserves gray levels. It’s very useful for coloring and tinting.

Chapter 16: Using Blending Modes with Layers(13)

Luminosity

Is the inverse effect from the Color mode.

Chapter 16: Using Blending Modes with Layers(14)
